R1700
RONWIN
HS Code: 8431390000
Character & Advantage of R1700 Bulk Material Handling Roller
Bulk material handling roller is also called sealed idler, it is mainly applied as belt supporting roller of bulk in mining or dock, also could be applied in hard environment of timber processing or outdoor and rainy condition.
The roller adopts labyrinth sealed structure, form a complex, curing and matched labyrinth channel between inside and outside sealing parts, well waterproof and dustproof.
Meet the requirement of MT821 about the supporting roller.
Working temperature range -10℃ to +40℃.
Diagram of R1700 Bulk Material Handling Roller
Dimensions & Alternative Surface Treatment of R1700 Bulking Handling Roller
| dia.×T | shaft dia. | flat milling | b×h | material | Surface Treatment |
| Φ60×2 | Φ15 | E=W+10 | 12×10 | steel | zinc-plated, paint or powder coating |
| Φ76×3 | Φ20 | E=W+10 | 14×6 | steel | |
| Φ89×3/4 | Φ20 | E=W+10 | 14×6 | steel | |
| Φ108×3.5 | Φ25 | E=W+10 | 18×8 | steel | |
| Φ133×3.5 | Φ25 | E=W+10 | 18×8 | steel | |
| Φ159×4 | Φ30 | E=W+10 | 22×8 | steel |
Usually Mounting Method of R1700 Bulk Material Handling Roller-Flat milling
1. Originated from the mining idler, the round end of roller is machined flat to fix into the frame groove. Assembly and disassembly is very easy.
2. Roller radial direction is not bound, so it is suitable for supporting roller of belt conveyor, but not suitable for sprocket roller, poly-vee roller or other drive roller.
3. Creating other mounting way of end hole fixed with the frame, completely delete the possibility of shaft roating, mainly applied in adjustable accumulation roller.
