Steel Roller Bearing Assembly
This type of steel bearing assembly is suitable for the steel roller with diameter of 60mm, 76mm and 89mm. It is finished bearing assembly stamp bearing housing, end cap and precision ball bearing.
Roller tube wall thickness and matched shaft are as belowed specifications chart.
| tube out diameter (mm) | tube wall thickness (mm) | shaft diameter (mm) | material |
| Φ60 | 1.2/1.5/2.0/3.0 | Φ12/Φ15/Φ20 | carbon steel, stainless steel |
| Φ76 | 2.0/2.5/3.0/3.5 | Φ12/Φ15/Φ20 | carbon steel, stainless steel |
| Φ89 | 2.5/3.0/3.5/4.0 | Φ15/Φ20/Φ25 | carbon steel, stainless steel |
2D Drawing
Images
Applications
